Name: Bluesun JA Solar Panels Home Use Perc Mono Solar Panel 425w 430w 440W 450W 455W 500WSolar Panel for House
Brand: Bluesun Solar Co., Ltd.
Availability: InStock

Home Products Hot Sale Products

Bluesun JA Solar Panels Home Use Perc Mono Solar Panel 425w 430w 440W 450W 455W 500WSolar Panel for House

Product Details:

Contact Now

Detailed Product Description

品牌:	Bluesun	型号:	BSM455M-72HPH
原产地:	Anhui, China	电池片尺寸:	166mmx166mm
类型:	打击乐, 半电池, Perc半电池太阳能电池板价格	尺寸:	20941038 35MM, 20941038 35mm
组件效率:	20.8%	姓名:	太阳能电池板450w
太阳能电池:	166mm	细胞数:	144 (6*24)
重量:	25.5kg	前玻璃:	高透射钢化玻璃
框架:	阳极氧化铝合金	接线盒:	IP67额定
打包配置:	30pcs/托盘，150pcs/20'gp，660pcs/40'hq集装箱

Products Description

Electrical Characteristics
Model Number	BSM425M-72HPH	BSM430M-72HPH	BSM435M-72HPH	BSM440M-72HPH	BSM445M-72HPH	BSM450M-72HPH	BSM455M-72HPH
Testing Condition	STC
Maximum Power (Pmax/W)	425	430	435	440	445	450	455
Open Circuit Voltage (Voc/V)	48.3	48.5	48.7	48.9	49.1	49.3	49.5
Short Circuit Current (Isc/A)	11.23	11.31	11.39	11.46	11.53	11.60	11.66
Voltage at Maximum Power (Vmp/V)	40.5	40.7	40.9	41.1	41.3	41.5	41.7
Current at Maximum Power (Imp/A)	10.50	10.57	10.64	10.71	10.78	10.85	10.92
Module Efficiency(%)	19.6	19.8	20	20.2	20.5	20.7	20.9
STC (Standard Testing Conditions): Irradiance 1000W/m², Cell Temperature 25 ℃, Spectra at AM1.5

Perc Cell

The PERC cell has a passivated rear side and a laser grooving process, which significantly improves the cell efficiency.

Certification

Projects

Bluesun‘s export volume is as high as 22GW, with projects in more than 185 countries around.

Configuration：425W Solar Panel EU Stock

Installation site：Croatia

Configuration：Energy Storage with 700W Double Glass Shingled Solar Panel

Installation site：U.K.

Configuration：440W Black Frame Shingled Solar Panel

Installation site：Sweden Gothenburg

Bluesun Company

Bluesun Solar---is one of the solar power solution leading companies in China. Specializing in research and development of solar panel, lithium battery and BMS.

Our Global Exhibition

INTERSOLAR EUROPE

INTERSOLAR MEXICO

INTERSOLAR AMERICA

THE FUTURE ENERGY SHOW PHILIPPINES

SOLAR SOLUTIONS INT AMSTERDAM

SOLAR & STORAGE LIVE UK

Production& Packing Process

Packing: By Carton box or Wooden Box

Payment

Payment Term	T/T	EXW	30% T/T in advance, paid the balance before shipment
			30% T/T in advance, paid the balance before shipment		FOB
				CNF	30% T/T in advance, paid the balance against copy of B/L
				CIF	30% T/T in advance, paid the balance against copy of B/L
		L/C	L/C amount above 50,000 usd, we can accept L/C at sight
		West Union	Amount lower than 5000usd
Delivery Time	7~10days after receiving payment for one container
More details please contact us.
