Name: Bluesun De Tier 1 330 Wp 340 Watt 350w 400watt500w 550w for Solar Panel System
Brand: Bluesun Solar Co., Ltd.
SKU: BSM350P-72
Availability: InStock

Home Products Small Solar Panel

Bluesun De Tier 1 330 Wp 340 Watt 350w 400watt500w 550w for Solar Panel System

Product Details:

Place of Origin:	Anhui, China
Brand Name:	Bluesun
Model Number:	BSM350P-72

Contact Now

Detailed Product Description

Cell Size:	158.75mmx158.75mm	Type:	PERC, Polycrystalline Solar Panel
Panel Dimensions:	195699240mm	Panel Efficiency:	22%
Junction Box:	IP67 Waterproof	Product Name:	Solar Panel
Warranty:	25 Years Solar Panel, 10 Years	Certificate:	TUV/IEC61215/IEC61730/CEC/CE/PID/ISO
OEM:	Accepatable	Frame:	Anodized Aluminium Alloy
Solar Cell:	Poly 156*156 Cell	Connector:	PV Compatible Connector
Application:	Solar Panel System

Product Description

Moduel	BSM325P-72	BSM330P-72	BSM335P-72	BSM340P-72	BSM350P-72
Rated Maximum Power at STC	325W	330W	335W	340W	350W
Open CircuitVoltage(Voc/V)	46.0	46.1	46.3	46.5	46.9
Maximum Power Voltage(Vmp/V)	37.17	37.6	37.9	38.2	38.5
Short Circuit Current(Isc/A)	9.05	9.28	9.36	9.45	9.6
Maximum Power Current(Imp/A)	8.74	8.78	8.84	8.9	9.09
Module Efficiency(%)	16.77	17.00	17.3	17.5	18.0
Power Tolerance	-0~+5W
Standard Test Condition(STC)	Irradiance 1000W/m2,Cell Temperature 25℃,Air Mass1.5

Detail

Glass

> Antireflective glass
> Translucency of normal luminance is increased by 2%
> Module efficiency is increased by 2%
> Self-cleaning function
> Service life is as long as 25 years (30 years optional)

Solar Cell

> High Efficiency PV Cells
> Appearance Consistency
> Color sorting ensure consistent appearance on each module
> Anti-PID

Frame

> Conventional frame
> Silver or black frames are optional
> Boost bearing capability and prolong service life
> Serrated-clip design tensile strength
> Seal-lip designglue injection

Junction box

> Conventional standalone edition and engineering custom edition
> Quality diode ensures module running safety
> IP67 protection level
> Heat dissipation
> Long service life

Produce Line&Packing

By Sea	Delivery from Shanghai or Ningbo seaport
By Air	Departure from Shanghai Pudong Airport
By Express	By TNT/DHL

Certifications

Payment

Payment Term	T/T	EXW	30% T/T in advance, paid the balance before shipment
			30% T/T in advance, paid the balance before shipment		FOB
				CNF	30% T/T in advance, paid the balance against copy of B/L
				CIF	30% T/T in advance, paid the balance against copy of B/L
		L/C	L/C amount above 50,000 usd, we can accept L/C at sight
		West Union	Amount lower than 5000usd
Delivery Time	7~10days after receiving payment for one container
