Bluesun Solar BSM460M-72HBD Half Cell 460W 455W Bifacial Double Glass Solar Panel in USA Stock

Product Details:

Contact Now

Detailed Product Description

品牌:	Bluesun	型号:	BSM460M-72HBD
原产地:	Bangkok, Thailand	电池片尺寸:	166mmx166mm
类型:	打击乐, 半电池, 异面, 双层-玻璃, 光伏建筑一体化	尺寸:	20941038 35mm(82.4440.871.18英寸)
组件效率:	21.2%	上市融资:	Goodleap，马赛克
列出的货架:	Ecofasten, Ironridge, PanelClaw	框架:	阳极氧化铝合金
前玻璃:	2.0毫米 (0.08英寸) AR涂层半Tempred玻璃	背面玻璃:	2.0毫米 (0.08英寸) 半Tempred玻璃
接线盒:	IP68 3旁路二极管	电缆截面尺寸:	12AWG
包装配置:	36pcs/托盘，648pcs/40HQ	证书:	ETL/CEC (加利福尼亚)/FSCE (佛罗里达)
保修期:	30年

Products Description

Bifacial PERC

For a bifacial PERC cell, the Al back surface field is replaced by Al grid, hence render the majority of rear side transparent which enable the cell to absorb light and generate electricity from both sides.

Electrical Characteristics
Model Number	BSM440M-72HBD	BSM445M-72HBD	BSM450M-72HBD	BSM455M-72HBD	BSM460M-72HBD
Maximum Power (Pmax/W)	440	445	450	455	460
Open Circuit Voltage (Voc/V)	49.2	49.4	49.6	49.8	50.0
Short Circuit Current (Isc/A)	11.4	11.47	11.54	11.61	11.68
Voltage at Maximum Power (Vmp/V)	40.5	40.7	40.9	41.1	41.3
Current at Maximum Power (Imp/A)	10.87	10.94	11.01	11.08	11.15
Module Efficiency(%)	20.24	20.47	20.70	20.93	21.16
STC (Standard Testing Conditions): Irradiance 1000W/m², Cell Temperature 25 ℃, Spectra at AM1.5
