Bluesun Top Selling Monocrystalline 560w 550w Solar Panel 1000w Price Wholesale Solar Plates for Home

Product Details:

Contact Now

Detailed Product Description

品牌:	BLUESUN	型号:	BSM560M10-72HPH
原产地:	Anhui, China	电池片尺寸:	182mmx182mm
类型:	打击乐, 半电池, 全黑色, Standard	尺寸:	2278113435 Mm
组件效率:	21.3%	Open-Circuit Voltage:	50 V
Short-Circuit Current:	14.37A	Certificate:	TUV CE
Weight:	28.6kg	Frame:	Anodized Aluminium Alloy
Cell Type:	182mm Half Cut Cell	No. Of Bypass Diodes:	3
Junction Box:	IP68	Maximum System Voltage:	1500V DC
Operating Temperature:	-40°C~ +85°C	保修期:	25 Years

Products Description

Product Paramenters

SPECIFICATIONS
Module Type	BSM540M10-72HPH	BSM545M10-72HPH	BSM550M10-72HPH	BSM555M10-72HPH	BSM560M10-72HPH
Module Type		STC	STC	STC	STC	STC
Maximum Power (Pmax/W)	540	545	550	555	560
Operating Voltage(Vmp/V)	41.96	42.06	42.16	42.24	42.33
Operating Current(Imp/A)	12.87	12.96	13.05	13.14	13.23
Open-Circuit Voltage(Voc/V)	49.60	49.70	49.80	49.90	50.00
Short-Circuit Current(Isc/A)	13.74	13.84	13.94	14.04	14.14
Module Efficiency（%）	20.90	21.10	21.30	21.49	21.68
STC: Irradiance 1000W/m², Cell Temperature 25°C Air Mass AM1.5
