Name: Panel Solar Frame 35mm 455watt Tier 1 Factory Panel Pv Tuv Certificate Bluesun Solar Panel Cell 166mm
Brand: Bluesun Solar Co., Ltd.
Availability: InStock

Home Products 166mm Solar Panels

Panel Solar Frame 35mm 455watt Tier 1 Factory Panel Pv Tuv Certificate Bluesun Solar Panel Cell 166mm

Product Details:

Contact Now

Detailed Product Description

品牌:	Bluesun/OEM	型号:	BSM455M-HPH
原产地:	Anhui, China	电池片尺寸:	166mmx166mm
类型:	打击乐, 半电池, 标准太阳能电池板	尺寸:	20941038 35mm
组件效率:	20.9%	重量:	25.5kg
产品名称:	半电池太阳能电池板144电池单390w	太阳能电池板:	单声道455瓦
保修:	25年输出功率保证	应用程序:	太阳能发电系统
接线盒:	IP68额定	证书:	TUV/IEC61215/IEC61730/CEC/CE/PID/ISO
前玻璃:	3.2mm高传输	TPT背板:	白色或黑色
保修期:	15年

Products Description

Perc Cell

The PERC cell has a passivated rear side and a laser grooving process, which significantly improves the cell efficiency.

Electrical Characteristics
Model Number	BSM425M-72HPH	BSM430M-72HPH	BSM435M-72HPH	BSM440M-72HPH	BSM445M-72HPH	BSM450M-72HPH	BSM455M-72HPH
Testing Condition	STC
Maximum Power (Pmax/W)	425	430	435	440	445	450	455
Open Circuit Voltage (Voc/V)	48.3	48.5	48.7	48.9	49.1	49.3	49.5
Short Circuit Current (Isc/A)	11.23	11.31	11.39	11.46	11.53	11.60	11.66
Voltage at Maximum Power (Vmp/V)	40.5	40.7	40.9	41.1	41.3	41.5	41.7
Current at Maximum Power (Imp/A)	10.50	10.57	10.64	10.71	10.78	10.85	10.92
Module Efficiency(%)	19.6	19.8	20	20.2	20.5	20.7	20.9
STC (Standard Testing Conditions): Irradiance 1000W/m², Cell Temperature 25 ℃, Spectra at AM1.5

Projects

Bluesun‘s export volume is as high as 22GW, with projects in more than 185 countries around.

Configuration：425W Solar Panel EU Stock

Installation site：Croatia

Configuration：Energy Storage with 700W Double Glass Shingled Solar Panel

Installation site：U.K.

Configuration：440W Black Frame Shingled Solar Panel

Installation site：Sweden Gothenburg

Bluesun Company

Bluesun Solar, as one of the top solar integrated solution provider in China, is a high-tech manufacturer specializing in R&D of solar panels,lithium battery and ESS.
