Product Details:
Place of Origin: Anhui, China
Brand Name: Bluesun/OEM
Model Number: BSM500PM5-72SB
Contact Now
Detailed Product Description
Cell Size: 166mmx166mm Type: PERC, Half Cell, All Black, Overlap
Panel Dimensions: 2056*1140*35mm Panel Efficiency: 21.3%
Solar Cell: Mono 166*166mm Product Name: Overlap Solar Panels
Application: Solar Power System Aluminium Alloy Frame: Silvery Or Black
Warranty: 25 Years Output Power Guarantee, 12YEAR Solar Panel: Mono 500w
Certificate: TUV/IEC61215/IEC61730/CEC/CE/PID/ISO/INMETRO Junction Box: IP67 Rated
Weight: 25kg TPT Back Sheet: White Or Black

Products Description
Bluesun Shingled Solar Panels 500w Home Power Station Pv All Black Roof Energy Sun Power Solar System Use 0
Shingled Module Technology
Compared with the normal module technology, the interconnected material of shingled module is different from that of normal module, whose technology is simpler and more reliable, avoiding the defects such as deviation of ribbon and cold soldering.
Product Paramenters
Electrical Characteristics
Model
BSM470PM5 -72SB
BSM475PM5 -72SB
BSM480PM5 -72SB
BSM485PM5 -72SB
BSM490PM5 -72SB
BSM500PM5 -72SB
Max Power(Pmax) [W]
470
475
480
485
490
500
Open Circuit Voltage(Voc) [V]
46.4
46.5
46.6
46.6
46.7
46.8
Short Circuit Current(lsc) [A]
13.04
13.10
13.16
13.22
13.28
13.40
Max Power Voltage(Vmp) [V]
38.6
38.7
38.8
38.8
38.9
39.0
Max Power Current(lmp) [A]
12.18
12.27
12.37
12.50
12.60
12.82
Module Efficiency [%]
20.1
20.3
20.5
20.7
20.9
21.3
Power Tolerance
0-5W
Max System Voltage
1000V/1500V/DC(IEC)
Max Series Fuse Rating
20A
Operating Temperature
-40 °C to + 85°C
STC
Irradiance 1000W/m2, cell temperature 25 °C , AM1.5
Advantages Of Shingled Module
Bluesun Shingled Solar Panels 500w Home Power Station Pv All Black Roof Energy Sun Power Solar System Use 2
Advantages
*Under the load of IEC 5400Pa, shingled has no new micro-cracks, although both shingled module and half-cell module passed the test(attenuation < 5%).
*High load resisting capacity reduces the production of micro-crack during transportation and power station installation.
Bluesun Shingled Solar Panels 500w Home Power Station Pv All Black Roof Energy Sun Power Solar System Use 4
Bluesun Shingled Solar Panels 500w Home Power Station Pv All Black Roof Energy Sun Power Solar System Use 6
Our Company
Bluesun Shingled Solar Panels 500w Home Power Station Pv All Black Roof Energy Sun Power Solar System Use 8
Global Exhibitions
Bluesun Shingled Solar Panels 500w Home Power Station Pv All Black Roof Energy Sun Power Solar System Use 10
Project
Bluesun Shingled Solar Panels 500w Home Power Station Pv All Black Roof Energy Sun Power Solar System Use 12
Payment


Payment Term


T/T
EXW

30% T/T in advance, paid the balance before shipment
FOB
CNF

30% T/T in advance, paid the balance against copy of B/L
CIF
L/C
L/C amount above 50,000 usd, we can accept L/C at sight
West Union
Amount lower than 5000usd
Delivery Time
7~10days after receiving payment for one container
