Name: Bluesun Photovoltaic Panel Solar Mono 400W 410W 420W 425W Half Cell Solar Panel Black Frame Costo for Home Use
Brand: Bluesun Solar Co., Ltd.
Availability: InStock

Home Products Other Solar Panel

Bluesun Photovoltaic Panel Solar Mono 400W 410W 420W 425W Half Cell Solar Panel Black Frame Costo for Home Use

Product Details:

Contact Now

Detailed Product Description

品牌:	Bluesun	型号:	BSM425G12-54HPH
原产地:	Anhui, China	电池片尺寸:	182mmx182mm
类型:	半电池, PREC	尺寸:	17221134 30mm, 17221134 30mm
组件效率:	21.7%	太阳能电池:	182 * 182mm, 单晶
重量:	23.0kg	接线盒:	IP67
电缆:	4mm2	前玻璃:	高透射钢化玻璃
打包配置:	36个/箱，936个/40'hq容器	连接器:	PV兼容
保修:	25年

Products Description

Product Paramenters

SPECIFICATIONS
Module Type	BSM410G12-54HPH			BSM415G12-54HPH			BSM420G12-54HPH		BSM425G12-54HPH
	STC	NMOT	STC	NMOT	STC	NMOT	STC	NMOT
Maximum Power (Pmax/W)	410	306	415	310	420	314	425	318
Operating Voltage (Vmpp/V)	31.43	29.3	31.64	29.6	31.83	29.8	32.03	30.0
Operating Current(Impp/A)	13.05	10.42	13.13	10.48	13.21	10.54	13.29	10.60
Open-Circuit Voltage (Voc/V)	37.50	35.30	37.75	35.50	38.00	35.70	38.25	35.90
Short-Circuit Current (Isc/A)	13.94	11.24	14.02	11.30	14.10	11.36	14.18	11.42
Module Efficiency qm(%)	21			21.3			21.5		21.7
STC: Irradiance 1000W/m . Cell Temperature 25℃, Air Mass AM1.5 NMOT: Irradiance at 800Wm . Ambient Temperature 2(TC. Air Mass AM1.5, Wind Speed 1m/s

Certificate

Projects

Packing & Delivery

Products Description

Product Paramenters

SPECIFICATIONS
Module Type	BSM410G12-54HPH			BSM415G12-54HPH			BSM420G12-54HPH		BSM425G12-54HPH
	STC	NMOT	STC	NMOT	STC	NMOT	STC	NMOT
Maximum Power (Pmax/W)	410	306	415	310	420	314	425	318
Operating Voltage (Vmpp/V)	31.43	29.3	31.64	29.6	31.83	29.8	32.03	30.0
Operating Current(Impp/A)	13.05	10.42	13.13	10.48	13.21	10.54	13.29	10.60
Open-Circuit Voltage (Voc/V)	37.50	35.30	37.75	35.50	38.00	35.70	38.25	35.90
Short-Circuit Current (Isc/A)	13.94	11.24	14.02	11.30	14.10	11.36	14.18	11.42
Module Efficiency qm(%)	21			21.3			21.5		21.7
STC: Irradiance 1000W/m . Cell Temperature 25℃, Air Mass AM1.5 NMOT: Irradiance at 800Wm . Ambient Temperature 2(TC. Air Mass AM1.5, Wind Speed 1m/s
