Name: High Power Bluesun Perc Mono Solar Panel Perc Half Cut Solar Panels 24 Volt 144cell
Brand: Bluesun Solar Co., Ltd.
Availability: InStock

Home Products Other Solar Panel

High Power Bluesun Perc Mono Solar Panel Perc Half Cut Solar Panels 24 Volt 144cell

Product Details:

Contact Now

Detailed Product Description

品牌:	Bluesun	型号:	BSM385M-72HC
原产地:	Anhui, China	电池片尺寸:	158.75mmx158.75mm
类型:	打击乐, 半电池, 单声道	尺寸:	1987992 40mm
组件效率:	22%	太阳能电池板:	Mono385w
应用程序:	太阳能发电系统	产品名称:	Ja半电池太阳能电池板385w
重量:	23kg	太阳能电池:	单声道156.75 * 78.375mm
保修:	25年输出功率保证	接线盒:	IP67额定
证书:	TUV/IEC61215/IEC61730/CEC/CE/PID/ISO/INMETRO	铝合金框架:	银色或黑色
保修期:	25年

1.Higher Yield Due to Better Shading Response

Half Cell Module comprises two separated and identical solalr cell arrays, which means the ordinary strings of cells are cut into halves, and these shorter strings compose which has separated current paths. When a module is shaded, only one side shaded array's current will be impacted, while the other array will still be functionally producing power. Under this circumstance, when a module is shaded, the affected working areas of Blade will be 50% less.
By cutting solar cell into halves, the internal power loss will be lower and hot spot effect will also be reduced.

2.Less Mismatch Loss

Instead of 6 internal strings of cells, half cell module has 2*6 shorter ones. This design effectively deals with the mismatch happened between cells caused by shadow, out of sync performance degradation, etc.

Half Cell Module Electrical Parameters At STC
Model	BSM375M-HC	BSM380M-HC	BSM390M-HC	BSM400M-HC	BSM410M-HC
Nominal Power	375W	380W	390W	400W	410W
Open-circuit Voltage	48.4V	48.6V	49V	49.24V	50.12V
Short-circuit Current	10.17A	10.26A	10.44A	10.57A	11.14A
Maximum Power Voltage	40.2V	40.4V	40.8V	41.17V	41.76V
Maximum Power current	9.34A	9.42A	9.57A	9.72A	9.82V
Module Efficiency	19.02%	19.28%	19.79%	20.61%	21.13%
Power Tolerance	0~+5W
Maximum System Voltage	1000V / 1500V DC(IEC)
Maximum Series Fuse Rating	15A
Operating Temperature	-40 ℃ to +85 ℃
	Irradiance 1000W/m²,module temperature 25, AM=1.5

Produce Line&Packing

(60cells )Container	20GP	40GP	40HC
Pcs/Pallet	30	30	30
Pallets/Container	14	28	28
Pcs/Container	400	840	924

(72 cells )Container	20GP	40GP	40HC
Pcs/Pallet	27	26	27
Pallets/Container	10	22	24
Pcs/Container	270	572	696

Certifications

Our Company

Bluesun Solar Co., Ltd. is a global clean energy solution service provider and high-tech photovoltaic module manufacturer. We are committed to providing one-stop energy solutions including energy supply, energy management and energy storage to customers around the world.

Feedback from our customers，if you want to know more information,please feel free to contact us,thanks!

Global Exhibition

Projects

Payment

Payment Term	T/T	EXW	30% T/T in advance, paid the balance before shipment
			30% T/T in advance, paid the balance before shipment		FOB
				CFR(C&F)	30% T/T in advance, paid the balance against copy of B/L
				CIF	30% T/T in advance, paid the balance against copy of B/L
		L/C	L/C amount above 50,000 usd, we can accept L/C at sight
		Paypal	Amount lower than 5000usd
		West Union	Amount lower than 5000usd
Delivery Time	7~10days after receiving payment for one container
